Temp-1Wire IP67 (1m, 3m, 10m)

Temperature sensor (-10°C to +80°C) with a metal housing with IP67 protection. Supplied in 3 lengths.

Available products

Temp-1Wire 1m IP67
Temperature sensor  (-10°C to +80°C), 1m cable, IP67 watertight version, probe encased in stainless steel cover (17241). Plug as sensor to the RJ11 1W-UNI.

Temp-1Wire 3m IP67
Temperature sensor  (-10°C to +80°C), 3m cable, IP67 watertight version, probe encased in stainless steel cover (17241). Plug as sensor to the RJ11 1W-UNI.

Temp-1Wire 10m IP67
Temperature sensor  (-10°C to +80°C), 310m cable, IP67 watertight version, probe encased in stainless steel cover (17241). Plug as sensor to the RJ11 1W-UNI.

Sensors can be daisy-chained

RJ11 temperature sensors can be daisy-chained using the sensors with 2 RJ11 ports (HTemp-1Wire-Box2, Temp-1Wire Rack 19). Temp-1Wire is designed for connecting to Poseidon, Ares, and STE family devices.
Features:
  • Temperature probe (-10°C to +80°C) for general usage
  • Stainless steel casing with IP67 classification
  • High protection against water and total dust protection
  • Sensor can be immersed to up to 1m
  • Temperature measuring in all IT, home, and industry environments
  • Temperature probe for both outdoor and indoor use
Applications and usage:
  • Temperature measurement in IT and industry
  • Temperature monitoring in storage and technology rooms
  • Not recommended for Cryo applications (use Pt1000 low-temperature version)
  • For fridge temperature monitoring use the Temp-1Wire-Flat 3m with flat cable.

Horizontal menu

Sensors wiring options

2 sensors - 2 ports

  • It's 2 separated RJ11 ports, but device show it as 3 different sensor values. Two different physical sensors, but 3 unique IDs.
  • To identify sensors in one housing disconnect one of them and it will apperar as -999.9 value within cca 15 seconds.



Daisy chain – 60m maximum total length

  • Some sensors can be easily used in daisy-chain (serial connection) due to 2x RJ11 port on the sensor.
  • A 3m RJ11 connection cable is usually included.
  • The total wiring length should not exceed 60 meters from an active port.



4 active ports - 4x 60m

  • One RJ11 sensor in each port is typical application
  • The total wiring length should not exceed 60 meters from an active port.
  • After autodetection (device setup), sensors cannot be moved between individual RJ11 active ports. When a sensor / RJ11 port connection changes, Sensor autodetection needs to be done again from the device setup.





The information about time-related sensors' precision and the need for calibration can be found in this application note https://hw-group.us/support/sensor-accuracy-over-time.

You can also get a sensor with a calibration protocol.
