Monitoring

The first procedure explains steps of setting when the sender phone number is included in ARES device list – there is not needed to know the password.

1. Setting of portal address SETCFG portal­_server=http://sensdesk.com/portal.php
2. Portal switching on SETCFG portal_cfg=1
3. Proceeding of manual Push Push

Similar procedure of setting, when the sender phone number is not included in ARES device list using password:

The example below use default password 1234

1. Setting of portal address 1234 SETCFG portal­_server=http://sensdesk.com/portal.php
2. Portal switching on 1234 SETCFG portal_cfg=1
3. Proceeding of manual Push 1234 Push

1) First, open the HWg-SMS-GW3 web administration at the General setup tab. The most important parameters are IP Address and Port. Copy the IP Address (192.168.100.174 in this example) and enter it in HWg-WLD.

2) Once the IP address of HWg-SMS-GW3 is determined, open the HWg-WLD web administration interface at the Remote SMS tab.

3) Enable the SMS Gateway and enter the IP address, the port and the phone number for receiving notifications. If the HWg-SMS-GW3 is secured, also enter the username and password. Finally, enter the SMS text. Remember to save everything. Depending on the desired SMS format, the default text can be used.

4) Then, select the test to perform. Both variants should be tested. The information window displays a successful test result.

5) If the test completed correctly, go to the Sensors tab and enable the Remote SMS option.
